Code: P0135 - O2 Sensor Heater Circuit Bank 1 Sensor 1

Oxygen sensor errors are quite common in older vehicles (including Toyota, Renault, KIA, Nissan, Hyundai, Volkswagen, Ford, Mercedes, BMW, Škoda, and others) and affect the emissions system. It is essential to address these issues promptly to maintain fuel efficiency and pass the emissions test.

When your OBD-II scanner displays code P0135, it means that the engine control module (ECM) has detected a problem with one of the oxygen sensors responsible for regulating the air-fuel mixture. The appearance of code P0135 indicates that the heater circuit of the O2 sensor in the exhaust system (specifically, sensor 1 in bank 1) has failed multiple automatic startup tests and requires inspection.

Causes of OBD P0135

In most cases, code P0135 indicates that the engine control module (ECM) has detected one of three potential problems during startup: excessive electrical load, a break, or a short circuit in the oxygen sensor circuit. This code may also appear if the ECM detects these issues while the vehicle is running.

Since these issues point to an electrical fault, it is likely that you will need to check the electrical connections and the condition of the oxygen sensor heater circuit.

Symptoms of P0135 Error

The engine control module (ECM) relies on data from the oxygen sensor heater to manage the air-fuel mixture. If the heater circuit of the sensor does not heat up to the required temperature to begin transmitting output voltage to the ECM, the vehicle may continue running at idle.

If the check engine light comes on, and there is unstable engine performance during startup, this may indicate the presence of code P0135 or a similar code related to the oxygen sensor. Additionally, if the idle or check engine light disappears after the vehicle warms up and idles for some time, it may point to a fault in the oxygen sensor heater circuit.

How to Diagnose DTC P0135?

Fixing code P0135 (heater circuit malfunction) can be done step by step. Here are some tips on how to address the issue on your own:

Start with a visual inspection of all electrical connections and components leading to oxygen sensor bank 1, sensor 1. Pay attention to this step, as damaged or worn insulation that may be causing the P0135 code can be easily overlooked.
Connect an OBD-II scanner and use it to record trouble codes and freeze frame data. This will help track and analyze the problem.
Use the "live data" function on your scanner (if available) to monitor data from the oxygen sensor. You will quickly spot if the sensor is not providing the correct voltage or current.
Measure the voltage at the oxygen sensor connector to ensure it matches the input voltage between the ECM and the problem circuit of the oxygen sensor heater.
Use a multimeter to check the resistance of the oxygen sensor heater circuit and ensure it meets manufacturer specifications.

How to Avoid Common Mistakes with OBD Code P0135?

Fixing electrical issues in a car requires thoroughness and systematics. Failing to pay attention to the smallest details, such as the check engine indicator LED, or skipping certain steps, can lead to unnecessary component replacements. Many people make mistakes when attempting to resolve issues related to code P0135.

Here are some common mistakes to avoid:

Insufficient inspection of moisture around the oxygen sensor wiring bundle. If water enters through damaged seals or weak connections, it can damage the wiring or the sensor.
Not considering the possibility of contamination from oil or carbon buildup on the new oxygen sensor. Delayed repair of the oxygen sensor can lead to carbon buildup in the exhaust system, which can damage various components.
Not properly checking the resistance, voltage, and current on the new oxygen sensor to ensure correct operation of the wiring bundle and connection to the ECM.
Replacing components before performing a thorough visual inspection and testing of the entire wiring with a multimeter. Replacing the oxygen sensor may be unnecessary if damaged wiring causing the P0135 code is not fixed first.

How Serious is Error P0135?

This issue is serious because without properly functioning oxygen sensors, the ECM cannot adjust the engine's fuel injectors to achieve the correct air-fuel ratio. This can lead to a cycle where the ECM cannot properly regulate the engine, resulting in engine overloading, wasted fuel, and excessive carbon dioxide concentration, potentially causing significant damage to the exhaust system or other engine components.

How to Fix Code P0135?

Here are some general methods to fix issues related to code P0135, which can help prevent long-term damage:

Replace the oxygen sensor (O2). This may not be the most economical option, but it is often effective. However, make sure the problem is actually with the oxygen sensor before proceeding. Failing to do this can lead to unnecessary spending without solving the issue.
Repair or replace the wiring and connections to the oxygen sensor. Repairing the wiring and connectors should be your first step when facing oxygen sensor issues. This is important to avoid unnecessary repairs and save time.
Replace the heater circuit fuse after fixing the short circuit between the oxygen sensor and the ECM. This is a fairly cost-effective and likely the best option when dealing with code P0135. Fixing the short circuit involves applying automotive electrical tape over the damaged insulation, removing the old fuse, and installing a new one.

Conclusion

Increased idle speed during startup and the check engine light may not always indicate a fault in the oxygen sensor heater circuit, but practice shows that it is a likely cause. When the engine light is on, use an OBD-II scanner to check for code P0135. If you're unsure about your abilities, take your vehicle to a local service center for diagnosis. Experienced mechanics can detect even small wiring defects and connector issues that most mechanics overlook. A skilled technician can quickly resolve the problem, saving you time and money.
