Code: P0123 - Throttle/Pedal Position Sensor/Switch "A" Circuit High

P0123 is a common OBD-II code applicable to Nissan, Toyota, Kia, Renault, BMW, Skoda, Ford, Mercedes Benz, Volkswagen, and other brands. It indicates that the engine control unit (ECU) has detected an issue with the throttle position sensor/pedal position switch, which is mounted on the throttle body at the top of the engine. The output voltage of circuit A has exceeded the expected voltage specification range for the sensor.

The throttle position sensor/pedal position switch controls the airflow into the engine by responding to accelerator pedal movement. The engine control module uses the measured voltage to control emissions, including the air-fuel ratio and ignition timing.

Causes of OBD P0123

The malfunction occurs when the output voltage of the pedal position sensor/switch range A circuit on the ECU exceeds 4.54V for more than two seconds. When this happens, it may indicate an issue with the sensor itself, such as improper installation or the need for replacement.

Other causes include faulty wiring/connections to the throttle position sensor/switch, or contamination of the throttle body. Carbon buildup in the throttle body can also lead to this fault.

Symptoms of P0123 Error

When this issue occurs, the check engine light will illuminate, and the ECU will enter a safety mode. The ECU will stop sending power to the throttle actuator, causing the throttle valve to close to less than six degrees of plate opening.

The ECU will control the engine RPM by adjusting fuel injection and valve timing. The exact symptoms depend on the vehicle's make and model, but expect difficult starting, high idle RPM, and poor throttle response.

The vehicle may still drive, but it will be very slow with limited throttle response.

How to Diagnose DTC P0123?

Check for faults by performing a scan and documenting the error codes. The snapshot data during the scan shows when the code was set.
Then, clear the OBD-II fault codes and run another test to see if the codes reappear.
Once the fault is confirmed, check the connections of the pedal position sensor/switch and the wiring for any short circuits or damage. Since faulty wiring is often the cause, the issue may be limited to a bad connection.
Repair any short circuits in the wiring or connections, but continue reviewing the data from the scanner to ensure the fault is completely resolved.
Compare the pedal position sensor/switch A and B data on the scanner. If discrepancies are found between the data points, perform a spot check of the pedal position sensor/switch according to the vehicle manufacturer's recommendations.
Finally, replace the throttle position sensor/switch based on accurate test results and clear the codes from the scanner. Test the vehicle on the road to ensure everything is working correctly and the symptoms have disappeared.

How to Avoid Common Mistakes with OBD P0123 Code?

When trying to fix the P0123 code, many fail to perform a visual inspection of the wiring and connections. These issues are the most common cause of P0123 codes, so checking the connections first can save a lot of trouble.

Be sure to scan, document, and clear the codes once, then repeat the check again. Verifying the fault ensures appropriate resolution.

After replacing the sensor, repair and check all connection issues. After testing, double-check the full connection.

Many people rush to replace the pedal position sensor or the corresponding switch without first confirming that this part is the actual cause of the issue. To avoid unnecessary costs and mistakes, make sure the voltage on circuits A and B is within the acceptable range before performing any repairs, and after the repairs. After replacing the pedal position sensor or switch, check the voltage again to ensure proper operation.

How Serious is the P0123 Error?

The engine control module and the pedal position sensor or switch are key elements in detecting the P0123 error code. This error forces the engine management system into a fail-safe mode, which can cause several engine performance issues, including stalling, insufficient acceleration, unstable idle, jerking during motion, increased idle RPM, and limited top speed.

For your safety and the safety of others, take immediate steps to address this issue.

How to Fix P0123 Code?

P0123 is relatively easy to fix. The code can be resolved by repairing or replacing the wiring and/or the pedal position sensor/switch connection.

If the pedal position sensor/switch is faulty, replace the part to fix the issue. Be sure to check connections and verify the voltage in the circuits to avoid having to go back and start over.

Conclusion

Whenever an issue arises with your engine, it’s important to address it as soon as possible. In the case of the P0123 code, engine performance will be significantly affected. Although specific issues vary depending on the vehicle, the ECU enters safety mode, which needs to be fixed.

Follow the steps above to diagnose and relatively easily resolve the malfunction.
